Game Boy Color 2.45" IPS LCD Backlight Kit with Laminated Lens and OSD - Hispeedido

DOCUMENTATION:

• Install Guide
• How to test your LCD kit.

NOTES:

• OSD can be operated with touch sensors (no soldering required) or button presses (requires soldering).
• Touch the two touchpads for 5 seconds to active the OSD menu.
• Touch the left touchpad to select an option when OSD Menu activated.
• Touch the right touchpad to adjust the option when OSD Menu activated.

• Shell trimming required on all shells - laminated or non-laminated. See install guide.

WARNINGS:

• You do not need to purchase a separate lens. Removing pre-adhered lens from LCD can result in damage to the LCD and will void product warranty. If you received an extra lens in your order, this was likely a included plastic lens with a shell and should NOT be placed on top of the pre-adhered lens.
• Test before installation! When you receive a backlight/LCD kit, you should perform a dry run before installing to assure that nothing has been damaged in transit. A dry run or test fit means the kit is not installed in the shell. This includes the use of adhesives, brackets, and any performed soldering. All ribbon cables should have no bends or creases in them. If you are unsure how to perform a dry run, please contact our support team and we will be happy to help. Backlight kits that have been installed are not eligible for replacement or return.

• LCD may break if put under too much pressure or dropped. Please exercise extreme caution when installing.

• Damage to console or LCD may occur if you do not trim the cartridge port pins. Exercise caution when trimming pins, wear eye protection to protect from pin debris when cutting the metal. Damage caused by these pins are not covered under our return or exchange policy. Trim the pins of your Gameboy's cartridge slot flat so that they don't interfere with any parts of the kit. We also recommend placing some Kapton tape over the trimmed pins to prevent any shorts.
