Game Boy Advance V5 IPS LCD Backlight Kit with Laminated Lens and OSD - Hispeedido

Price
$64.99 USD
Color:Black
In stock! Usually ships within 1-2 business days.
SKU: GBA2006
Pickup available at 519 Davisville Rd.

Usually ready in 2-4 days

View store information
A new Laminated IPS Kit for you Game Boy Advance.

FEATURES:

  • V5 Laminated OEM size Lens
  • Drop-in ready/compatible with Hispeedido Laminated Shells.
  • 720x480 Resolution
  • PCB embedded in the LCD.
  • Built-in OSD Menu. Soldering required.
  • Retro pixel Effects: Normal, Retro pixel (like original AGS-101 LCD), Scanline 1, Scanline 2.
  • 15 brightness levels.
  • 8 color modes.
  • Frame blending function.
  • Touch Screen to change the brightness and the color modes.
  • Compatible with 32-pin and 40-pin GBA Console.

INCLUDED:

  • 1 x IPS LCD with adhered lens (see warnings) and attached PCB with two pre-soldered touch sensor wires
  • 1x 40 pin ribbon
  • 1x 32 pin ribbon
  • 3 x Wires

PAIRS WELL WITH:

DOCUMENTATION:

NOTES:

  • At this time, the Laminated IPS Shell For Game Boy Advance - Hispeedido is the only shell (laminated or non-laminated) we would recommend for this kit as the kit was made to be paired with this shell. All non-laminated shells may require heavy trimming in order to be compatible.
  • Not compatible with FunnyPlaying laminated shells or other laminated shells.
  • This kit can be paired with IPS Modified Prestige Shell for Game Boy Advance - RetroSix but it is not recommended - install at your own risk. If pressure spots are noted on the LCD or general fitment issues, a small amount of trimming may be necessary on the shell. Please see product photo that indicates the area of which to trim and how much.
  • Applicable console text on lens.
  • White and Black variants have holographic text on lens.

OSD Menu Operation:

  • Press the Select+L+R buttons for 1 second at the same time, then release the buttons to activate the OSD Menu.
  • Press the Select button to select the adjustment item when OSD Menu activated.
  • Press the L or R button to adjust the item when OSD Menu activated.
  • Press the Select+L+R buttons for 1 second at the same time, then release the buttons to save & exit, or allow for screen timeout.
  • Alternatively, holding select and pressing L or R will decrease or increase the brightness level when not using the OSD menu.

Touch Sensor Operation:

  • Tap the bottom touch sensor to adjust brightness in a loop. Hold the bottom touch sensor and the pixel effects will start scrolling automatically, release when the desired effect is reached.
  • Hold the top touch sensor and color modes will start scrolling automatically, the top touch sensor does not have a function for tap.

WARNINGS:

  • You do not need to purchase a separate lens. Removing pre-adhered lens from LCD can result in damage to the LCD and will void product warranty. If you received an extra lens in your order, this was likely a included plastic lens with a shell and should NOT be placed on top of the pre-adhered lens.
  • Test the kit before installation! Once the display is mounted with the included double-sided foam tape, it cannot be safely removed. We ask that you test the kit by hooking it up before removing the screen protector and before mounting the display using the foam tape.
  • LCD may break if put under too much pressure or dropped. Please exercise extreme caution when installing.
