SALE

Game Boy Advance SP IPS Backlit LCD Kit - Unbranded

Game Boy Advance SP | GBA SP Collection by Hand Held Legend

$54.99 USD Sale price

Compare at $59.99 USD

Regular price $54.99 USD
*PHOTO REQUIRES UPDATE* Item shown is the Funnyplaying version
Description
Add this Game Boy Advance IPS LCD to your Game Boy Advance SP to make your play more enjoyable with a modern display, featuring enhanced brightness, color and clarity!
Funnplaying brand here



Contents

  • 1x IPS Backlit Screen
  • 1x Ribbon Cable (V2)
  • Glass Lens
  • Foam backing

Notes

  • V2 has no more screen tearing!
  • some case modification required
  • Supports brightness adjustment, soldering required
  • There is a black protective film covering the LCD
Warning
  • LCD may break under pressure or if dropped. We recommend you exercise care when installing this product.
  • Please pay attention to prevent static electricity during installation. Wear static electricity bracelet before installation in dry environment.
  • Test the kit before installation! Once the display is mounted it cannot always be safely removed. We ask that you test the kit by hooking it up before removing the screen protector and before fully mounting the display.



TFT vs IPS displays



TFT

IPS

General information

Works when the backlight is off, and will look similar to the stock display.

Only works when the backlight is on.

Outdoors

Visible outdoors and indoors, even in bright light.

Poor visibility outdoors or in bright light.

Power

Very power efficient.

Higher power consumption relative to TFT and stock displays.


Crisp image, but not to the same degree as an IPS display.
Viewing angles quickly lose quality.

More crisp in presentation relative to the TFT display.
Viewing angles retain color and sharpness.

Installation

Essentially a drop-in kit that doesn’t require any shell modification. The mod can be undone if desired.
No soldering needed.

Requires shell modification, some of which can be seen in clear shells. Due to the shell modifications, the mod is not able to be undone.
Soldering needed to enable the brightness control.



Installation

Knowledge Base

Note: Commission may be earned from the links provided above

*PHOTO REQUIRES UPDATE* Item shown is the Funnyplaying version
Description
Add this Game Boy Advance IPS LCD to your Game Boy Advance SP to make your play more enjoyable with a modern display, featuring enhanced brightness, color and clarity!
Funnplaying brand here



Contents

  • 1x IPS Backlit Screen
  • 1x Ribbon Cable (V2)
  • Glass Lens
  • Foam backing

Notes

  • V2 has no more screen tearing!
  • some case modification required
  • Supports brightness adjustment, soldering required
  • There is a black protective film covering the LCD
Warning
  • LCD may break under pressure or if dropped. We recommend you exercise care when installing this product.
  • Please pay attention to prevent static electricity during installation. Wear static electricity bracelet before installation in dry environment.
  • Test the kit before installation! Once the display is mounted it cannot always be safely removed. We ask that you test the kit by hooking it up before removing the screen protector and before fully mounting the display.



TFT vs IPS displays



TFT

IPS

General information

Works when the backlight is off, and will look similar to the stock display.

Only works when the backlight is on.

Outdoors

Visible outdoors and indoors, even in bright light.

Poor visibility outdoors or in bright light.

Power

Very power efficient.

Higher power consumption relative to TFT and stock displays.


Crisp image, but not to the same degree as an IPS display.
Viewing angles quickly lose quality.

More crisp in presentation relative to the TFT display.
Viewing angles retain color and sharpness.

Installation

Essentially a drop-in kit that doesn’t require any shell modification. The mod can be undone if desired.
No soldering needed.

Requires shell modification, some of which can be seen in clear shells. Due to the shell modifications, the mod is not able to be undone.
Soldering needed to enable the brightness control.



Installation

Knowledge Base

Note: Commission may be earned from the links provided above
