Game Boy Advance SP 3.0 Inch IPS LCD Backlight Kit M2 - FunnyPlaying
Game Boy Advance SP 3.0 Inch IPS LCD Backlight Kit M2 - FunnyPlaying
SKU : GBASP4200
FEATURES:
- More display effects and Mixed frame switch
- Touch sensor attached to ribbon cable for short press brightness adjustment and long press OSD menu.
-
OSD menu has 8 brightness levels, 4 color options, 3 display options, and frame blending.
- Fits in original (OEM) shells.
- Fits with aftermarket and IPS ready shells.
- Brackets needed to install with FunnyPlaying Mirror Clear ITA/IPS shells.
- Logo text on glass lens is holographic.
INCLUDED:
- 1x 3.0 Laminated IPS M2 LCD with adhered lens (See Warnings)
- 1x PCB
- 1x Ribbon with touch sensor attached
- 1x Wire
PAIRS WELL WITH:
- GBA SP IPS Mirror Clear Shell Bracket - FunnyPlaying
- GBA SP ITA/IPS Mirror Clear Shell - FunnyPlaying
DOCUMENTATION:
- How to test your LCD kit
- FP Install Guide - *FunnyPlaying did not include the bracket needed to help install this kit into their Mirror Clear ITA/IPS modified shells. If you are using the FunnyPlaying Mirror Clear shell, you can use these brackets instead.
NOTES:
To use the brightness button for OSD menu:
- Long hold (3 to 5 seconds) the brightness button to open the OSD
- Press the button once to change the currently highlighted option
- Long hold the brightness button again to switch highlighted options
- To close the OSD simply don't press the brightness button for 5 seconds
To use the touch sensor for OSD menu and brightness:
- Short press (one to two seconds) adjusts brightness levels without entering OSD menu. Long press (3 to 5 seconds) will open OSD menu.
- Long press again to change menu selection.
- Tap/short press to adjust selection in menu.
- To close the OSD simply don't press/tap the sensor for 5 seconds.
WARNINGS:
- You do not need to purchase a separate lens. Removing pre-adhered lens from LCD can result in damage to the LCD and will void product warranty. If you received an extra lens in your order, this was likely a included plastic lens with a shell and should NOT be placed on top of the pre-adhered lens.
- Test before installation! When you receive a backlight/LCD kit, you should perform a dry run before installing to assure that nothing has been damaged in transit. A dry run or test fit means the kit is not installed in the shell. This includes the use of adhesives, brackets, and any performed soldering. All ribbon cables should have no bends or creases in them. If you are unsure how to perform a dry run, please contact our support team and we will be happy to help. Backlight kits that have been installed are not eligible for replacement or return.
- LCD may break if put under too much pressure or dropped. Please exercise extreme caution when installing.
Friendly Returns
Secure Checkout
1-2 Days Shipping
Prompt Customer Support
Upon testing the Display when received, every thing checked out. Turns on , touch button pad worked, and all options worked. It wasn’t until the display was fully installed in the SP shell when you could notice the display alignment was off. I really look forward to resolving this issue with support as I am very excited to finish my build.
Thanks for your feedback! If you have already emailed our support team, please send us a message again. We do not believe you have contacted us yet regarding the matter and we would be happy to assist!
Title said it all. Installation was very easy overall. End result looks alot better then original.
received the screen and tested before install as instructed and it did not function. requested return exchange. This review might change if they send one that works.
Thanks for your review! It looks like support resolved this for you and the issue was just a ribbon being inserted incorrectly. We hope you are enjoying the kit and would appreciate an updated review if you have a moment. :)
Great drop in screen. I prefer the menu and brightness adjustment settings built into the touch display versus needing soldering to access the menu.
Very nice display, I like the fact that there is a display mode to keep a retro touch (with slight scanline effect) with nice colors.
I was just surprised that the PCB wasn't attached like on the pictures on the side of the screen, but rather on the bottom. The link for the installation tutorial show the right version. There are also some more osd options than on the description here.
I always love using these kits, they work amazing and work great. Cant recommend enough.
