Game Boy Pocket Q5 IPS LCD Backlight Kit with OSD - Hispeedido

Price
$58.99 USD
In stock! Usually ships within 1-2 business days.
SKU: GBP4100
Pickup available at 519 Davisville Rd.

Usually ready in 2-4 days

View store information

OSD WILL NOT FUNCTION WITHOUT A GAME BEING INSERTED INTO THE CONSOLE

Upgrade your Game Boy Pocket (GBP) with this Game Boy Pocket IPS LCD Backlight Kit with OSD. IPS LCD's are characterized as having the best color and viewing angles available today. Take your old and outdated reflective pocket display to a bright and colorful upgrade your 10 year old self could only dream of.

FEATURES:

  • Built-in 36 retro color combination
  • 11% larger than the original LCD
  • Overall power consumption between 0.3 - 0.8W
  • Accurate aspect ratio
  • Contrast wheel brightness function
  • On screen controls allow you to move the display window for perfect centering with vertical and horizontal adjustments.
  • The On Screen Display (OSD) menu has functions for Brightness, Vertical Position, Horizontal Position, Pixel Effect, Battery Meter, Color Adjust, and Factory Reset.
  • Use the Left touch sensor to change color, (Hold to turn on/off pixel effect) Use the Right touch sensor to change brightness, (Hold to turn on/off Battery display meter)
  • "BAT" point on PCB is pre-tinned.
  • Case modification and soldering required

INCLUDED:

  • 1 x Q5 IPS LCD
  • 1x PCB with pre-soldered touch sensor wire
  • 1x Ribbon
  • 1x Touch sensor ribbon
  • 1x Adhesive
  • 2x Insulation film
  • 4x Wires

USING THE OSD:

  • Hold Select and press A + B simultaneously to access the OSD menu.
  • Press A and B to scroll through the menu (A=Up, B=Down).
  • Hold Select and press A to enter a function.
  • Press A or B to set desired level (A=Right, B=Left).
  • Hold Select and press A to save changes.
  • Hold Select and press B to exit.

    DOCUMENTATION:

    NOTES:

    • After installation, if it is noted that your touch sensor is overly sensitive or is cycling, please see this article for assistance.

    WARNINGS:

    • Test before installation! When you receive a backlight/LCD kit, you should perform a dry run before installing to assure that nothing has been damaged in transit. A dry run or test fit means the kit is not installed in the shell. This includes the use of adhesives, brackets, and any performed soldering. All ribbon cables should have no bends or creases in them. If you are unsure how to perform a dry run, please contact our support team and we will be happy to help. Backlight kits that have been installed are not eligible for replacement or return.
    • LCD may break if put under too much pressure or dropped. Please exercise extreme caution when installing.
      Shipping Information

      Our on-line store is open 24/7 and we ship Monday through Friday, excluding some holidays. Most products ship within 1 business day from our warehouse in Pennsylvania USA. Orders will be shipped in the order they are received. Please select a shipping speed according to your needs.

      About Us

      Hand Held Legend is committed to keeping retro gaming alive and better than ever. Upgrade your childhood consoles with modern tech. We strive for excellence in all that we do and aim to serve our customers well.

      Customer Reviews

      Based on 21 reviews
      57%
      (12)
      19%
      (4)
      14%
      (3)
      5%
      (1)
      5%
      (1)
      L
      Luis Andreu
      OSD Issue

      After following the Q5 IPS LCD installation video step by step, I noticed that the OSD function kept popping up on the screen during game play every time I press the "A" button. After several on line searches of such issue, I did not find a possible fix or solution. Therefore, I had no choice but to disable the OSD function by desoldering the "A", "B" and "Select" wires from the PCB that was included with the purchased IPS kit. Without game play the OSD function work well. Right now the Q5 IPS LCD is operating in default mode with touch sensors functionality. NO OSD Functionality.

      Thanks for reaching out! Please reach out to support@handheldlegend.com so we may look into this further with you!

      r
      r.g.
      Bad scanlines

      The screen is really not of good quality and terrible scanlines spoil the experience.

      Thanks for your review! Please reach out to us at support@handheldlegend.com so we may look into this further with you.

      D
      Danny
      Amazing

      love the quality of the screen 36 Templates i can pick from. will buy again for a personal build

      A
      Albert G
      Great!

      Great screen! Easy to install but a little time consuming. I didn’t think I’d use the color options that much but I love them!

      E
      Eric
      Worth the money and the effort. Just be prepared and know what it takes to install.

      This kit was on sale for $50 when I got it, and after having installed it, I'd say that price is just about right. It is certainly not the easiest kit out there, and I would not recommend it to beginners, but the juice is worth the squeeze. The OSD and touch sensors make it a pleasure to use. One note, I also installed a power regulator, as I believe the GBP really needs it when it comes to these IPS screens. Overall happy with my purchase, and hope others here like it as well!

      M
      Michael
      Awesome kit for my favorite version of gb

      Worked and fit was great love playing my gbp again over my other modded consoles.
